It is mainly used for highly fluid foods, crops, pharmaceuticals, and chemical products. For example, it can vertically transport granular or blocky products such as potato chips, peanuts, candy, dried fruit, frozen food, vegetables, and chemical drugs from a low position to a high position.
Product Performance
| 1 | The hopper is cast from food-grade polypropylene material, featuring an attractive appearance, resistance to deformation, and resistance to both high and low temperatures. |
| 2 | The chain bucket elevator can perfectly achieve continuous or intermittent conveying and can be integrated with other feeding equipment. |
| 3 | The chain bucket elevator is easy to assemble and disassemble, and the hoppers are easy to clean. |
Technical parameters
| Model | JC-3100B |
| Power | 0.75KW |
| Conveying Capacity | 3-6 m3/h |
| Voltage | 220V/380V 50HZ |
| Hopper Material | Food-grade polyethylene (PE) plastic |
| Discharge Port Height | 3100mm |
| Material | 304# stainless steel |
